Rear view camera for Fiat Ducato, Peugeot Boxer, Citroen Jumper

DBC 114082 BL

Rear view camera integrated in specially designed brake light bracket for mounting on Fiat Ducato (also new Ducato 2014), Peugeot Boxer and Citroen Jumper from 09/2006 onwards.
The intelligent sophisticated brake light bracket uses the existing brake light housing at the rear of the vehicle.

request product find a merchant
  • description
    • Rear view camera integrated in specially designed brake light bracket for mounting on Fiat Ducato (also new Ducato 2014), Peugeot Boxer and Citroen Jumper from 09/2006 to 2014
    • The intelligent sophisticated brake light bracket uses the existing brake light housing at the rear of the vehicle
    • The small dimensions and the aerodynamic design guarantees a trouble-free installation and operation
    • Easy and fast installation – no drilling required!
    • Resistant against vandalism and moisture due to extremely sturdy ABS plastic housing and integrated rubber seal (IP68)
    • Minimum illumination (0,1 lux)
    • 150° viewing angle
    • Automatic electronic iris
    • High resolution with 420 TV-lines
  • specifications
    Image-Sensor 1/4" CMOS ASX 340 CS sensor
    Resolution 640(H)x480(V); 420 TV lines
    Visual angle 150°
    Lens F1.2
    Illumination 0,1 Lux
    Video-System PAL
    Guide-Lines no
    Camera-Input MINAX
    Protection class IP 68
    Operating temperature range -20 °C bis + 70 °C
    Storage temperature range -40 °C bis + 80 °C
    Power supply 12 V
    Power consumption max. 40 mA
    Dimensons (WxHxD) 340x70x31 mm
    Weight
    Certification ECE-R10





  • shipment

    DBC 114080 Y - Camera

    WPC 6 (20 m connection cable)

  • downloads

    DBC 114082 BL - Datenblatt

    Download
Technical changes and errors excepted.
