7" LCD-TFT AHD Monitor for Camera Systems

CRV 7112 M

7" (17.78 cm) AHD rear view monitor with 3 camera inputs.
Easy to install and connect (plug & play).

request product find a merchant
    • 7" (17.78 cm) rear view monitor with 3 inputs
    • 3 camera inputs (AXION DIN system)
    • Easy to install and connect (plug & play)
    • Operating menu in 7 languages
    • Touch control buttons
    • 3 trigger input signals
  • Screen diagonal7 inch
    Screen resolutionRGB 1024 x 600
    Screen brightness500 cd/m²
    Viewing angler/l :65°/65° , o/u: 40/15 °
    Image reflectionyes
    Video systemAHD 1080p/720p and PAL / NTSC (automatic)
    Day/night switchingyes, sensor
    Loudspeakeryes
    Camera input3x AXION 4p DIN
    Control lines (trigger)3
    Power supply12/24 V
    Power consumption< 6 W
    Operating temperature-20 °C to + 70 °C
    Storage temperature-30 °C to + 80 °C
    OSD (operating menu)7 languages
    Dimensions (LxWxH)180 x 120 x 25 mm
    Test marks, certificatesECE-R10
    • CRV 7112 M - Monitor
    • Connection cable set
    • Sun visor
    • Monitor stand
  • Download
Technical changes and errors excepted.
